UTV Front-mount push tubes Quick attach Code: 20.7400

Brand:                    IB
Material:              Steel
Surface:              Powder coated
Weight:               44.31 lbs
Product dimensions:            700 x 450 x 200 mm
Packed dimensions:             760 x 490 x 220 mm

Iron Baltic quick attach push tube.

Suitable to use with;
04.100 Straight plow blade 1280mm (also as a bucket / with bucket conversion kit)
04.300 Straight plow blade 1500mm
20.7700 Plastic plow blade 1500mm
04.800 Straight plow blade 1800mm
20.7200 High throw blade 1500mm
20.7300 High throw blade 1800mm
20.7600 Modular 2-in-1 bucket
20.1000 Push broom 1500mm

*use push tube p/n 34.4000 for the UTV V-plows


Model specific, reinforced UTV mounting adapter needed for installing the UTV push tubes (standard front mount adapters are not compatible to use with UTV push tubes).

Compatible mounting adapter part numbers are: 03.7000, 03.7900, 03.9800, 03.10600, 03.11800, 03.12100, 03.12700, 03.13000, 03.13200, 03.13400
Simple Installation - Quick attach: Easy on / Easy off.
No reduction in ground clearance.
Improved Lift Height.
Impact reducing springs.
5 different working angle positions (quick & easy adjustment).
Blade angle adjustment.
Mount is located at the front of the vehicle - no need to crawl under the ATV.
Requires specific heavy duty UTV front mount adapter to install.
Will not fit with normal / ATV front mount adapters!
Detailed user manual is included.
